FLANGED CONNECTOR BODY, 206036-2, AMP CPC, 3 CIRCUIT, SHELL SIZE 17, THREAD, PINS, STANDARD SEX | 3CP-C317P-THFCommon plug with convenience power for John Deere and Case IH/CNH, OEM vehicles for auxiliary powerMating Connector Parts:Backshell: Size 17 SKU# 3CP-BS17S OEM# 206070-8 Sealing Cap: Size 17 SKU# 3CP-CAP17 OEM# 208652-1Flange Gasket: Size 13 SKU# 3CP-FL17 OEM# 81665-2Terminal: Pins SKU# 3CP-PPWR OEM# 66261-4 Standard Circular Connector STD SQUARE RECP 17-3DescriptionProduct AttributeManufacturerTE ConnectivityHeight36.45 mmConnectorsStandard Circular ConnectorContact GenderWithout Pin ContactsDiameter26.67 mmFlammability RatingUL 94 V-0Housing MaterialNylonLead Free Solder ProcessesNot relevant for lead free processMating StyleThreadedMounting AngleStraightMounting StylePanelMounting TypeFlange with Mounting HolesNumber of Positions3 PositionPackagingBulkProductHousingsProduct TypeStandard Circular ConnectorSeriesCPCShell MaterialPolyamide (PA) When purchasing AMP CPC Connectors (AMP Circular Plastic Connectors) there are a couple things to keep in mind.There are 3 things needed to complete the standard connector kitConnector Body – see connector bodiesContact/Terminal – see contact/terminalsBackshell/Strain Relief – see accessoriesWe have several pre-assembled kits to choose from to make ordering easier. see pre-assembled AMP CPC KitsChoosing the correct wire gauge and being mindful of wire insulation is imperative when ordering the correct terminals. If you need support, don’t be afraid to reach out. That’s what we’re here for, we’re here to help, that’s what we do!
[email protected] trouble finding or identifying the correct connector body? Shoot us a picture. Text us a picture to 270-978-3198 or email us at
[email protected]. We’ll follow up and help you choose.Using the right tooling can make all the difference! Did you know CrushinAG offers tooling for everything we sell? So, what do you need for AMP CPC Connectors?Signal Pins & Socket Crimper Tool MULTIMATE CONTACTS; 58495-2 DIE; PRO-CRIMPERSignal Pins & Sockets Extraction Tool AMP 305183 EXTRACTION TOOL, AMP TYPE XII CONTACTSPower Pins & Sockets Crimper Tool YELLOW, 474FL, RATCHETING CRIMP TOOLPower Pins & Sockets Extraction-Removal Tool AMP 91124-1 PWR CONTACT EXTRACTION TOOLImportant information to know about wiring, connectors and AMP CPCSeries 1—Size 16 ContactsSeries 1 connectors permit the use of multiple combinations of signal and coaxial circuits in the same housing by accepting durable Multimate contacts. These pin and socket contacts include Type III and subminiature coaxial contacts, Interchangeable in the same Multimate contact cavity.Type III contacts (.062 [1.57] pin diameter) are capable of carrying a maximum of 13 amperes when crimped in wire.Type III solder contacts and posted contacts for pc board applications are also available. Many connector arrangements offer both standard and reverse sex contact loading, from 4 thru 37 positions.Series 3—Power ContactsSeries 3 connectors accept Type XII power contacts which can carry up to 25 amps per contact. These contacts will accommodate a wire size range of 16 to 10 AWG [1.4 to 5 mm2]. Two connector sizes are available in both standard and reverse sex connector arrangements 3 and 7 positions.Series 4—CombinationSeries 4 connectors accept Size 16 Multimate and Type XII power contacts, combining the signal and coaxial circuit capabilities of Series 1 connectors with the power circuit capabilities of Series 3 connectors. Available in two connector sizes offering power mixing combinations totaling 16 and 22 positions.Connector Size—In general, with more circuits in a connector, less current per contact can be carried.Wire Size—Larger wire will carry more current since it has less internal resistance to current flow and generates less heat. The wire also conducts heat away from the connector.Current Load Distribution—Spreading those lines with greater current loads throughout the connector, particularly around the outer perimeter, will enhance heat dissipation.Ambient Temperature—With higher ambient temperatures, less current can be carried.Current Rating VerificationCan a contact rated at 10 amps carry 10 amps?Maybe yes, but probably not. The reason lies in the test conditions used to rate the contact. If these conditions do not adequately reflect the application conditions, the actual allowable current levels may be lower than specified levels. For example, many manufacturers, including Tyco Electronics, test a single contact in air. This gives an accurate measure of the basic current-carrying capacity of the contact. Use the contact alone in air and it can certainly carry 10 ampere. Use it in a multi-position connector surrounded by other current carrying contacts or in high ambient temperatures, and the contact should carry less current. Similarly, as the contact ages and stress relaxation, environmental cycling, and other degradation factors take their toll, the contact’s current carrying capacity decreases. A prudent design must set current levels for such end-of design-life (EODL) conditions. Practical current-carrying capacity is not an absolute, but an application-dependent condition.
